Project Description
Bell Helicopter 206L3 with new avionics package and ADS-B out compliant. New interior and paint 2020. Aircraft boasts a utility configuration with corporate appeal.
SOLD – 1990 Bell Helicopter 206L3 – N220MH
HELICOPTER INFORMATION |
|
| Year | 1990 |
| Manufacturer | Bell Helicopter |
| Model | 206L3 |
| Price | SOLD |
| Location | U.S.A. |
| Serial Number | 51359 |
| Registration | N220MH |
| Total Time | TTAF 11,767 Hrs |
Utility
Leisure
| EQUIPMENT & ACCESSORIES | |
| Dual Calipre Rotor Brake Kit | Dual Controls |
| Wire Strike Protection System | Facet External Oil Filter |
| Paravion Bleed Air Heater | Air Comm A/C with Dual Evaporators |
| High Skid gear with Flite Steps | Tail Rotor Pedal Lockout Kit |
| Cyclic and Collective Safety Covers | Baggage Door Retention Strap |
| Crew and Pax Door Openers | Rubber Mounted Crew and Chin Windows |
| Cargo Hook Provisions | Crew and passenger USB charging ports |
| Donaldson Inlet Barrier Filter Kit | |
| AVIONICS | |
| Flight instrument kit | Garmin 530W GPS/VHF |
| Garmin 350HC Audio Panel | Garmin GTX335 Transponder |
| Garmin GTR225 Comm Radio | Garmin GRA55 Radar Altimeter Unit |
| Sandia Aerospace GI205 Radar Altimeter Ind | ACK E-04 ELT |
| COMPONENT STATUS | ||
| Component | Hours Remaining | OH/Insp./RT |
| Engine: | ||
| Turbine | 2,000 | OH |
| Wheel 1 | 2,025 | RT |
| Wheel 2 | 2,025 | RT |
| Wheel 3 | 2,564 | RT |
| Wheel 4 | 2,564 | RT |
| Compressor | 2,000 | Insp. |
| Impeller | 12,616 | RT |
| Governor | 1,940 | OH |
| Fuel Pump | 2,577 | OH |
| Fuel Nozzle | 1,742 | OH |
| Fuel Control | 2,077 | OH |
| Bleed Valve | 355 | OH |
| Components: | ||
| MR Hub assy | 2,400 | OH |
| MR Blade 1 | 3,363 | RT |
| MR Blade 2 | 3,363 | RT |
| MR Mast assy | 1,668 | OH |
| MR Mast Pole | 2,962 | RT |
| MR Transmission | 4,500 | OH |
| Swashplate assy | 2,495 | OH |
| TR Gearbox assy | 6,000 | OH |
| TR Hub assy | 1,168 | OH |
| TR blade 1 | 2,455 | RT |
| TR blade 2 | 2,455 | RT |
| Freewheeling assy | 3,000 | OH |
| Servo 1 | 908 | OH |
| Servo 2 | 809 | OH |
| Servo 3 | 2,466 | OH |
| The Bell Helicopter 206L3 Longranger | |
| Performance | Dimensions |
| Cruise speed – 109 knots | Size (feet) – 34.2 L x 7.6 W x 9.9 H |
| Range – 317 Nautical miles | Empty weight – 2,200 lbs. |
| Ceiling – 20,000+ feet | Max gross weight – 4,150 lbs. |
| Rate of Climb – 1,340 feet / minute | Fuel capacity – 100 gallons / 743 lbs. |
| Cabin | Lift |
| Crew (typical) – 1 or 2 | External load – 1,250 lbs. |
| Passenger (typical) – 5 or 6 | Internal load – 1,000 lbs. |
| Storage – 16 cu ft. | |
